SPECIFICATION :
Frame
Genius Carbon / IMP / HMF /
BB92 / Alloy swingarm with 180PM
U-Mono Link / Tapered Headtube
IDS SL DM dropouts for 142x12mm
BB height adj.
Travel
700 Series: Front 150mm
Rear 150 - 100 - Lockout / Shock 200X57
900 Series: Front 140mm
Rear 130 - 90 - Lockout / Shock 190X50
Fork
FOX 34 Float Performance Air
Grip 3 / 3-Modes / 15x100mm QR axle / tapered steerer
Reb. Adj. / Lockout
Rear Shock
FOX NUDE SCOTT custom w. travel / geo adj.
3 modes: Lockout - Traction Control -Descend
DPS / EVOL / Reb. Adj.
Remote System
SCOTT TwinLoc TSP Technology
Suspension - Seatpost Remote
Below Bar / 3 modes / integ. Grip clamp
Headset
Syncros Pro Press Fit / Tapered 1.5" - 1 1/8"
OD 50/61mm / ID 44/55mm
Rear Derailleur
Sram GX1 / 11 Speed
Front Derailleur
SCOTT Chainguide
Shifters
Sram GX1 Trigger
Brakes
Shimano M615 Disc
180mm F & R / SM-RT64 CL Rotor
Crankset
Sram Custom GX1 GXP PF
700 Series: 32T / 900 Series: 30T
BB-Set
Sram GXP PF integrated / shell 41x89.5mm
Handlebar
Syncros FL1.5 mini Riser / Alloy 7050D.B.
12mm rise / 9° / 760mm
Syncros Pro lock-on grips
Handlebar Stem
Syncros TR1.5
2014 / 3D forged / oversize 31.8mm
1 1/8" / 700 Series: +6° / 900 Series: -6°
Seatpost
FOX Transfer Dropper Remote
31.6mm / S size 100mm / M, L & XL 150mm
Seat
Syncros XM2.0 / CROM rails
Hub (Front)
Syncros TR2.5 CL / 15x100mm
Made by DT Swiss
Hub (Rear)
Syncros TR2.5 CL / 142x12mm
RWS axle
Made by DT Swiss
Chain
Sram CN-PC1110
Cassette
Sram XG1150 / 10-42 T
Spokes
DT Swiss Competition 2.0-1.8-2.0 Black
Rims
Syncros TR2.5 /28H
Tubeless ready
Tires
Schwalbe Nobby Nic EVO / 2.35
67EPI Kevlar Bead / Tubeless Easy
PaceStar compound
Weights
12.70kg / 28lbs
